Yash Metal & Steel Pvt. Ltd. had several years of experience in manufacturing ALUMINIUM 1100 Plates. Our company is renowned to manufacture the desired product with correct dimensions and standards in accordance with client demand. ALUMINIUM is one such chemical element with symbol AI and 13 as atomic number. The pure aluminum is slightly slivery and soft with non-magnetic in nature. It is simply a boron group ductile metal found easily in Earth’s crust. We dig it out in its pure form and send it directly to our production unit so that sheets plates coil formation is made possible. Know more about it from below paragraphs.
Before you jump on the description of our manufactured product it is advisable to know little about aluminium. The metal is reactive and rare to find in the extremely difficult and reducing environment. It is used to form plates and sheets due to its low density as well as the ability to show excellent corrosion via a phenomenon called Passivation.
Its alloy is precisely been used in various industries requiring a high level of ductility, flexibility, and corrosion resistant. The aluminium and its alloys possess greater and strong corrosion resistance toward acid and other acidic solutions. The alloy is said to be highly sensitive at an elevated temperature ranging somewhat between 200°-250° C or 392-482° Fahrenheit. It may lose its strength due to a harsh and tough environment. However, it is said that the strength can be increased accordingly at subzero temperatures thus making it ideal alloy for low-temperatures.
The ALUMINIUM 1100 Plates are made using pure aluminium alloy that inherits excellent and magnificent forming characteristics and features. You can read more about the product when you are delivered a datasheet about aluminium 1100 alloy stating about physical properties, chemical properties, thermal properties, other designations in detail.
Machinability-Due to exceptional strength, the ALUMINIUM 1100 Plates has good machinability. It can be shown up with it is machined in a harder temper. High-speed tooling, as well as carbide tooling, can be used effectively on it. Oil lubricants are used in case heavy cuts are drawn.
Forming-both cold as well as hot forming gets performed easily on ALUMINIUM 1100 Plates. In annealed conditions, it can be worked extensively with cold methods.
Welding-using the entire range of conventional methods, it can be welded using suitable AL 1100 consumable electrodes.
Forging-- it can be forged without any difficulty
Hot and cold working-the aluminium alloy works tremendously in both cold as well as hot conditions. Thus it can be spinned, drawn or bent well. Due to its easy on eye machinability, forming, welding, forging, and hot & cold working, it is used in sheet related work in top industries.
Testing-After appropriately molding the raw aluminium in desired plates and sheets it is without any delay or interruption send to the testing unit. Here in the testing unit, a test like flexibility, flattening, and micro and macro test gets performed. When testing is approved and results are obtained it is passed to the packaging unit where wooden crates or wooden boxes are used for packaging. After it got packaged, it is transported to clients.
ASTM B209 / ASME SB209
0.2mm to 300mm
500mm - 2500mm
500-10000 mm
Mill, Customer specific finish
HR / CR Sheet / Plates/ Strips/ Coils/ Chequered Plates
UNS | Japan | USA | France | ISO |
---|---|---|---|---|
A91100 | JIS A1100P | AA1100 | NF 1100 | Al 99.0 Cu. |
Aluminium Alloy UNS A91100 Plate | Aluminium 1100 Tread Plates Stockists |
---|---|
Aluminium 1100 Circle Trader in India | 1100 Aluminium CR Sheets |
Aluminium 1100 Blank Dealer in India | Aluminium 1100 Ring Distributor in Mumbai |
Aluminium 1100 Foil Manufacturers | 1100 Aluminium Strip Stockholder |
Aluminium 1100 Hot Forming Plate | 1100 Aluminium Sheet & Plate |
ASTM B209 Aluminium A91100 Plate Supplier | Commercial Aluminium 1100 Plate Exporter in India |
ASME SB209 Aluminium 1100 Plate | 1100 Aluminium Checkered Plate |
Aluminium 1100 Hot-Rolled (HR) Plate | Aluminium 1100 Cold-Rolled (CR) Sheet |
Alloy 1100 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Cr | Others | AI |
---|---|---|---|---|---|---|---|---|---|---|
min. | 0.35 | 0.25 | 0.01 | 0.01 | 0.05 | 0.01 | 0.020 | Trace | 0.05 (each) | 99.60% |
max. | 0.50 | 0.35 | 0.03 | 0.05 | 0.20 | 0.05 | 0.030 | Trace | 0.15 (total) | remainder |
Alloy | Temper | UTS(Mpa) | % Elongation | |||
---|---|---|---|---|---|---|
Min | Max | 0.5 mm -0.8 mm | 0.81 mm - 1.30 mm | 1.30 mm - above | ||
1100 | O | 75 | 110 | 20 | 25 | 29 |
H12 | 95 | 130 | 5 | 6 | 7 | |
H14 | 110 | 145 | 3 | 4 | 5 | |
H16 | 130 | 165 | 2 | 3 | 4 | |
H18 | 150 | --- | 2 | 2 | 3 |
