What is SA 516 GR.60/70 Steel Plate ?

The Yash Metal is the organization growing their steps in the field of building and construction. They are known as great traders of the SA 516 GR.60/70 PLATE in a different variety of types and dimensions. They are known for their fine work for many decades and are very precious. They use good quality raw material which is collected from the finest mines and ores. They provide accuracy in the construction as they use highly advanced technology with much flexibility in the formation. The alloy used in the formation of these plates is having many useful features.

The SA 516 GR.60/70 PLATE is the steel grade plates available in many different specifications. This grade of steel plate is very popular in the market and is having much demand. The main and primary purpose of the steel plates is in the pressure vessels. These plates are made of an alloy having good welding abilities. These plates are having greater tensile strength. This alloy is having greater resistance to corrosion due to different factors like moisture, water, oxygen, and high-pressure steam. It can also easily resist different chemicals, toxic gases, and different oils.

Standard Specification for SA 516 GR.60/70 Plate
Equivalent Grades of SA 516 GR.60/70 Plate
Types Of SA 516 GR.60/70 Plate
Chemical Composition of SA 516 GR.60/70 Plate
Mechanical Properties SA 516 GR.60/70 Plate
People Also Searched for
Price of ASTM A516 GR.60/70 Plate
Makes of ASME SA 516 GR.60/70 Plate
Application of SA516 GR.60/70 Steel Plate

ASME SA516 Carbon Steel Plate, ASME SA 516 Grade 60 Steel Plates, SA 516 GR.70 Plate, SA 516 GR.60/70 Pressure Vessel Plates, SA 516 GR.60/70 Carbon Steel Plates Stockists in Mumbai, SA 516 GR.60/70 High Tensile Steel Plate Supplier in India. ASME SA516 GR.60/70 Carbon Steel Pressure Vessel Steel Plate, ASTM A516 Grade 70 Plate, A516 Gr 60 Plate Exporter, SA 516 GR.60/70 Boiler Plates Stockists in India, Carbon Steel ASME SA516 / ASTM A516 Grade 60 & 70 Plate Supplier in Mumbai.

The plates thus have greater toughness and hardness although they have a lesser thickness than other steel plates. These plates are very ductile in nature and thus it is available in different dimensions and sizes. There are various testing conducted over the steel plates like the ultrasonic test which is conducted as per SA 578, they also undergo the hydrostatic test and impact test which is conducted at various temperatures like -20 degree and -46 degree. This plate also undergoes the micro and macro test, and also intergranular corrosion test to examine the different responses towards different types of corrosives. It also undergoes bend test to know the tensile strength and elongation properties.

These plates constructed by Yash Metal are also certified with different certificates as manufacture test certificate according to EN 10204/3.2. The 100% high-quality raw material test and 100% radiography test. They also phase vacuum treatment, product analysis, simulated post weld heat treatment, additional tensile test, drop weight test, and vacuum carbon deoxidized steel test. The documents related to various testing are handed over previously to the customer before the delivery.

We are also very much responsible for the packaging of the products. The steel plates are packed in the boxes made of wood, steel or thermoplastic, especially build according to the size of the plates. The packaging can be customized also as per the customer’s demand. They are delivered within a few days of the order.

The Yash Metal is very much dedicated to their customers. We wish to provide everything to our customer as they need. Our industry is build up and managed by the team of experts having greater experience. We also provide the customized designs and dimensions of the product as per the desired need of the customer. We wish to provide a quality product at your doorsteps before time with perfect delivering and packaging.

Standard Specification

Standard

ASTM A516 / ASME SA516

Width

1000mm – 4500mm

Thickness

5mm - 150mm

Length

3000mm -18000mm

Process

Hot-Rolled (HR)

Destructive and Non-Destructive Testing

Mechanical examining like tensile, Elongation and reduction of area.
Chemical examination-Spectro analysis
Impact analysis
Hydrostatic analysis
Positive material recognition
X-ray test
Firmness test

ASTM A516 GR.60/70 Plate Processing

Cutting
Forming Drilling/ Machining
Grinding
Testing

SA 516 GR.60/70 Steel Equivalent Grades :

Grade	British Standard	European Norm	ASTM/ASME	DIN
SA516 Gr. 60	BS1501-161-430A	EN10028 P265GH	A/SA516 - Grade 60	DIN 17155 HII
SA516 Gr. 70	BS1501-224-490A/B	EN10028 P355GH	A/SA516 - Grade 70	-

Other Types

ASTM A516 Carbon Steel Plate Supplier	ASME SA 516 Carbon Steel Plate Exporter in India
SA 516 GR.60 Plates	SA 516 GR.60/70 BQ Plates Stockists
SA 516 GR.60/70 Boiler Quality Steel Plate	SA 516 GR.60/70 Hot Rolled Steel Plates Dealer
SA 516 GR.60/70 Plate Manufacturers	SA 516 Grade 60 Boiler Plate Stockholder
High Tensile SA 516 GR.60/70 Plate	Industrial SA 516 GR.60/70 Plates Trader in India
ASME SA 516 GR.60 Steel Pressure Vessel Plates	SA 516 GR.70 Pressure Vessel Plate Distributor
ASTM A516 GR. 60 Plates	ASTM A516 GR. 70 Plate

Chemical Composition of SA 516 GR.60/70 Plate

Grade	C	Si	Mn	P	S	AI	Cr	Cu	Ni	Mo	Nb	Ti	V
A 516 Gr. 60	0.20	0.4	0.95/1.50	0.025	0.025	0.02	0.3	0.3	0.3	0.08	0.01	0.03	0.02
A 516 Gr. 70	0.10/ 0.22	0.6	1/1.5	0.025	0.025	0.02	0.3	0.3	0.3	0.08	0.01	0.03	0.02

Mechanical Properties of ASME SA 516 GR.60/70 Plates

Grade	Tensile Strength	Yield Strength	Elongation min, %
SA516 Gr. 60	415-550 Mpa	250 Mpa	21
SA516 Gr. 70	485-620 Mpa	250 Mpa	21

People Searched For

asme/ a 516 gr. 60 steel plate price list, carbon steel sa516 grade 60 plate exporter in india, astm a516 grade 60 plate thickness tolerance, astm a516 grade 70 plate thickness, sa 516 gr.60/70 plates manufacturer in india, sa 516 gr.60/70 carbon steel boiler plates suppliers, carbon steel sa516 grade 70 plates dealer in mumbai, sa 516 gr.60/70 plates dealer in mumbai, sa 516 gr 70 temperature range, sa 516 gr 70 equivalent, sa 516 plate exporters in mumbai, sa 516 gr 70 plate manufacturers, sa 516 gr.60/70 in mumbai, sa 516 gr.60/70 carbon steel high tensile plate, sa 516 gr.60/70 plates in india, boiler steel sa 516 gr.60/70 plate, sa 516 gr 70 price in india, sa 516 gr.60/70 plate supplier in mumbai, sa 516 gr.60/70 plate manufacturers in mumbai, sa 516 gr.70 hr plate, astm a516 grade 60 and gr 70 plate traders in mumbai, sa 516 specification pdf, sa 516 gr 70 pdf, astm a516 gr.70 specifications, asme sa 516 gr.60/70 plate stockists in india, sa 516 steel grade 60/70 plate, sa 516 gr.60/70 plate suppliers in india, sa 516 specification, sa 516 gr 70 machinability, sa 516 gr.60/70 boiler quality plates, astm a516 gr.60 plate specifications, astm a516 gr 60 equivalent indian standard, sa 516 gr.60/70 carbon steel plate stockholder in india, sa 516 gr.60/70 pressure vessel plate, sa 516 gr.60/70 plates in mumbai, sa 516 gr.60/70 steel plate stockists in mumbai, sa 516 gr 60 temperature range, sa 516 gr 60 specification, sa 516 gr.60/70 in india.

Price Of SA 516 GR.60/70 Plates

SA 516 GR.60/70 High Strength Steel Plates Stock
US / Metric Ton (FOB Price) on request
SA 516 GR.60 HR Steel Plate
US / Metric Ton (FOB Price) on request
SA 516 GR.60/70 Boiler and Pressure Vessel Plate
US / Metric Ton (FOB Price) on request
SA 516 Grade .60/70 High Tensile Steel Plates
US / Metric Ton (FOB Price) on request
ASME SA516 / ASTM A516 GR.60/70 Boiler Plates
US / Ton (FOB Price) on request
ASME SA516 Gr 70 Hot Rolled Steel Plate
US / Ton (FOB Price) on request
SA 516 GR.60/70 Boiler Quality Plates
US / Ton (FOB Price) on request
